4 channel digital delay Generator

GFT1504

Features

  • 4 independent Delay Channels (10 in option)
    • 100 ps time resolution (1 ps in option)
    • 25 ps RMS jitter (channel to channel)
    • 10 second range
  • Channel Ouptut Pulse
    • 6 V / 50 Ω, 3 ns rise time
    • Independent control of width, polarity and amplitude
  • Independent trigger rate (repetititve or single) for every channel
  • External trigger mode from external input or internal trigger mode from two synchronous programmable timers
  • External clocking up to 90 MHz (in option)
  • Controlled via Ethernet, Web page and front panel
  • Compact packaging
  • Options:
    • Extension to 8 or 10 delay channels
    • Channel Output pulse 10V or 20V or 32V under 50 Ω or optical pulse

Features

  • 4 independent delay channels (8 in option)[br]
  • 100 ps delay resolution (1 ps in option)
  • 50 ps channel to channel jitter (5 ps in option)
  • 50 MHz rate
  • Output pulse 1.5 to 5 V / 50 Ω, 1 ns rise time  with Independent control of width, polarity, amplitude, and MUX mode
  • Independent trigger rate (repetitive, single or burst) for every channel
  • External trigger mode with pre-scaler or internal trigger mode from two synchronous programmable timers or command
  • Gate (or second trigger) input
  • External clocking up to 240 MHz (user programmable)
  • Controlled via USB and Ethernet (Bluetooth in option)
  • Ultra-compact packaging with low power consumption
  • In option output pulse amplitude can be 3 to 10 V or 15 V to 50 V or LVDS level
